Garmin ECHOMAP™ Ultra 2 12" Chartplotters Navionics+

Big screens, sharp detail, and serious fishfinding power—the Garmin ECHOMAP™ Ultra 2 12" delivers everything a modern angler needs. This premium chartplotter brings crisp WXGA touchscreen clarity to your helm with a sunlight-readable 12.1" display. Designed for anglers who rely on precision and situational awareness, it supports cutting-edge sonar like LiveScope™, Ultra High-Definition scanning, and CHIRP traditional sonar (when paired with compatible transducers). Whether you’re scouting ledges or dropping on deep marks, this is Garmin at full throttle.

Why Serious Anglers Choose Garmin ECHOMAP™ Ultra 2 12"

• Massive 12.1” IPS touchscreen – Bright, responsive, and fully sunlight-readable.
• LiveScope™ & UHD sonar support – Get full sonar power when paired with compatible gear.
• Garmin Navionics+™ built-in – Navigate with rich inland & coastal maps.
• Wireless networking – Share sonar, routes, and waypoints seamlessly.
• Multi-band GNSS – Superior position accuracy with GPS, GLONASS, Galileo & BeiDou.
• Screen recording – Capture and share catches or sonar findings instantly.

Technical Specifications

• Type: Fishfinder / GPS Chartplotter (No Transducer Included)
• Display: 12.1" WXGA IPS touchscreen (1280 x 800 px)
• Dimensions: 13.4" x 9.0" x 3.9"
• Water Rating: IPX7
• Networking: Wi-Fi, ANT+, NMEA 2000, Garmin Marine Network (2 ports)
• Memory: 2 microSD slots, 5000 waypoints, 50 tracks, 100 routes
• Sonar Capable: CHIRP, ClearVü, SideVü, LiveScope, Panoptix (w/ transducers)
• Mapping: Built-in Garmin Navionics+, Auto Guidance+, Quickdraw Contours
• Power: 9–18 VDC input, 36W max usage

Whether you're rigging a new build or upgrading your setup, the Garmin ECHOMAP™ Ultra 2 12" is ready to lead. Lock in the ultimate fishing advantage—add this beast to your boat today!

With Transducer

• ECHOMAP Ultra 122sv or 126sv (depending on the version selected) with optional Garmin Navionics+
• GT56UHD-TM transducer
• Power cable
• Bail mount with quick release cradle
• Protective sun cover
• Hardware
• Documentation

Without Transducer

• ECHOMAP Ultra 122sv or 126sv (depending on the version selected) with optional Garmin Navionics+
• Power cable
• Bail mount with quick release cradle
• Protective sun cover
• 8-pin transducer to 12-pin sounder adapter cable
• Hardware
• Documentation
