| Model |
XPLORE 10 CMSI+ Fish Finder |
| Product Code |
412010-1 |
| Series |
XPLORE |
| UPC |
0082324058677 |
| Display Size - Diagonal |
10.1 in |
| Display Pixel Matrix |
1280H x 800V |
| Transducer Included |
XM 14 HW CMSI T |
| Compatible With |
Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, Minn Kota Talon/Raptor, Minn Kota i-Pilot Link, Minn Kota Built-In MEGA SI, MEGA Live, NMEA 2000, MEGA 360, Radar, AutoPilot, One-Boat Network |
| Features |
Touch Screen, Networking, Down Imaging, Built In GPS, Bluetooth, Side Imaging, Built In Mapping, MEGA Imaging+, Wi-Fi, MEGA Imaging |
| Memory Card Slot |
Dual Micro SD |
| Sonar-Standard |
Dual Spectrum CHIRP, MEGA Side Imaging+, MEGA Down Imaging+ |
| Sonar-Optional |
50/83/200 kHz, Airmar High, High Wide, Medium, Medium Wide, and Low |
| CHIRP - Frequencies Supported |
Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz) |
| Sonar-Frequencies Supported |
50/83/200/455/800 kHz, HW DSC CHIRP, and MEGA |
| Depth-Sonar |
3,500 ft (optional 50 kHz), 1,200 ft (standard transducer) |
| CHIRP - Imaging Frequencies Supported |
455 kHz SI+ (405-505 kHz), 455 kHz (420-520 kHz), MEGA SI+ (1050-1175 kHz) |
| Depth-Down Imaging |
200 ft (MEGA), 400 ft (455 kHz) |
| Range-Side Imaging (Side-To-Side) |
800 ft (455 kHz), 250 ft (MEGA) |
| Interface |
Touch Screen, Keypad Control |
| Power Input |
10.8-20 VDC |
| Power Output Peak-to-Peak |
8000 Watts |
| Power Output RMS |
1000 Watts |
| Screen Snap Shot |
Included |
| Sonar Recording |
Included |
| Mount-Standard |
Gimbal |
| Mount-Standard Size |
12.098 in W x 7.702 in H x 3.891 in D |
| Mount-Optional |
In-Dash Mounting Kit |
| Mount-Optional Size |
12.098 in W x 7.702 in H x 3.891 in D |
| Transducer Mount Location |
Transom |
| GPS Chartplotting |
Included |
| GPS Receiver |
Internal |
| GPS Trackplotting |
Not Supported |
| Waypoints, Routes, Tracks/Points |
10,000, 50, 50/20,000 |
| 360 Imaging Compatibility |
Yes |
| MEGA Live Compatibility |
Yes |
| Humminbird Basemap |
Included |
| LakeMaster Compatibility |
Yes |
| CoastMaster Compatibility |
Yes |
| Navionics Gold/HotMaps Compatibility |
Yes |
| Navionics Platinum+ Compatibility |
Yes |
| Platinum Compatibility |
Yes |
| Minn Kota Advanced GPS Navigation Compatibility |
Yes |
| Minn Kota i-Pilot Link Compatibility |
Yes |
| Minn Kota Talon Shallow Water Anchor Compatibility |
Yes |
| Radar Compatibility |
Yes |
| 5-Port Ethernet Switch Compatibility |
Yes |
| AIS Compatibility |
Not Supported |
| Autopilot Compatibility |
No |
| Heading Sensor GPS Compatibility |
No |
| Heading Sensor GPS (NMEA 2000) Compatibility |
Yes |
| NMEA2000 |
Included |
| Target Separation |
2.5 in |
| Upgradable Software |
Yes |
| View Preset Keys |
Yes |
| X-Press Menu System |
Yes |
| Custom Digital Readout |
Yes |
| Custom View Selections |
Yes |
| Display Colors Grayscale |
24-Bit |
| Display Type |
Color TFT |
| Speed |
Included |
| Temperature |
Built In |
| Temperature Alarm |
Yes |
| Temperature Graph |
Yes |
| HDMI Compatible |
No |
| Warranty |
Two-Year Warranty |
